PROJECT 900

It looks like the same carbs are used on my 80 XS1100G Body wise any way.
Do those have Diaphrams there Wiz ?



Yes Fitz the rod sldes horizontally rather than rotating, I know not why.
Rpgoerlich, yes they have diaphrams, you can see them in the bottom picture, in their numbered trays, I am having the caps chromed, that's why they are not fitted.



Did you get the bowl sorted?



Well,I repaired the damage I did getting the drain screw out & am waiting for a 6mm x .75 plug tap from the States + a new screw, so I don't know if it is sorted, more a work in progress.
How is my NZ connection for parts progressing? Wiz.



It's here... Want me to add a float bowl to the list?



Yes please, right side 3 or 4. Wiz.



Done



At this stage of the strip down the bike takes on a very appealing rat look.



Headlight bucket, carrier & horns finished.



Did you get them powder coated or paint yourself?



Hi Alive. I usually use a good quality rattle can for the small black bits, I warm up the parts to be painted & put the can in hot water for 10 min's.



hmmmm can in hot water... That's a new one, might give that a go.

I sprayed the 750 engine paint with a heat gun in one hand and spray can in the other.... Worked really well



I ALWAYS warm up rattle-cans in a bowl of warm water before spraying; it's a trick I learned years ago building model airplanes.



I use my heat gun to heat up metal parts before painting - not only helps the paint adhere, but it dries the part of any solvents used beforehand.

I also have a butane blowtorch that I use for curing exhaust header paint - this way you can bolt the headers back on without marring the finish (and limits the smokeout when you first start the bike up 8O ).

Oops - sorry for the minor thread hijack wiz - neat work as always :wink:



No worries Hillsy, you're always welcome aboard. Wiz.



Brakes pretty much ready to go back on, after removing all the custard.
These are, of course, the opposing piston calipers, not the floating caliper used on the earlier XJs, this inovative design was taken from the Grand Prix bikes & was revolutionary. The modern high perfomance bikes use 4 or 6 opposing pistons.
You will stop eventually without either type of caliper, your deceleration caused by a combination of factors including aerodynamic drag forces, friction in the engine, gearbox, transmission and wheel bearings and the rolling resistance bteween your tyres and the road.



Good luck with it Wiz. I just overhauled my brakes too. Custard is a good description of the muck I found in the master cylinders. And dried custard in the calipers. I see you got the nice black painted calipers with the Yamaha badge. My front ones are just plain painted silver. I had to take them apart twice as I forgot to use the supplied assembly grease on the pistons.



There is no red line on the taco dial, is that the norm?



Mine red lines at 9500



Front mudguard bracket, to get to this stage:
Rotary wire brush to remove the oxide, then 180 grit, 240, 360, 400, 600, buffing wheel & finish with mothers ally pollish.



One down, one to go.
Move over 'Mothers' this is the new wonder product, repels dirt, marks & water for months.



...... dont tell me all you did was apply the cleaning wax to that one fork tube and it came out lookin like that, but that looks really nice



I would if I was trying to sell the stuff, it's good, but you still have to put the hard yards in.
Are you staying on campus, Schoot?



Just in case you thought I wasn't doing anything. pic'.



Not re-spraying the frame Wiz :?:



I havn't got that far yet Hillsy, I'm still stripping it down.



Oops - my bad. I thought you were on the re-assembly road after the engine re-build.



ya im stayin on campus.... i usually hop on the computer ever couple of hours cuz i either have a half hour or an hour before another orientation thing starts



Replacement 'piston rings' for the front fork damper rods are not to be had, so enter the $2 plumbing fitting, I will shave off 2# 3mm doughnuts & it's Miller time. :lol:



ONE of the hard parts of disconecting the final drive is holding back the rubber boot, introducing the 'retractor'.
Before pic swing arm & final drive.



Swing arm & final drive pics.



Probably did'nt look that good from the factory.
Looking good wizard



Very impressive on the final drive,Wiz. What did you do to get it looking like that ?

Cheers, Murray



chrome paint.



Outstanding.

While you have those parts totally accessible, ... you can add Pin Stripe Decals or other Stripe Decals and Clear over them.



Just ?



Yeah - chrome paint is magic. Don't need to prep or anything :lol:



Hello, all you 900 aficionados, these 4 lugs on the front of the tank, are they for fixing a faring? & if so & I am staying buff naked, can I just give them a new zip code? Wiz.



The nekkid versions had oil cooler shrouds that mounted there (one on either side).

And I think the half fairing versions mounted the fairing there (?)



No.
Those ate the Mounting Points for Plastic "Air Scoops"

OEM Air Soops are no longer available.
Being Mounted in those "Ears" with Rubber Grommets left them susceptible to falling off.

The Air Scoop was of an elongated-triangular design.
Deflector Panels within the Scoop directed On-rushing Air entering the scoop to the Canyon in the Head where the Spark Plugs fit.

http://cgi.ebay.com/ebaymotors/1983-YAM ... 500wt_1182



It won't look right without something there.
I'll send you pics and dimensions if you want to make something.



Found a pic :wink:



Wow that's a curve ball, WTF am I to do now?
answers on a postcard please. :?



How's your NZ parts connection??



I have just sent Alive a PM or should I say an SOS.



Frame prepped ready for painting.



Aye, Mates:

Just finished a very nyce dye withe non-uthah then membah redcentre3 from Don-undah.

The good man he is ... is bringing-back some XJ-Bits for the Aussie's.



The fuel tank on my XJ has those 4 lugs. They don't do anything. You can't see them with the fairing. The frame mounted fairing is on a mounting bracket, and some distance away from the tank. Here's a rather poor picture. The light wasn't very good today, and my phone camera doesn't have a flash.



gidday mate. anyhoo love that ultra large massive view mirrors. where on earth did u find em? custom made? toooo right, fair dinkam.



900 Owners

PM me your Email address, please.
I have a 900 related file to sent to each of you.
